Status:
Active
Weight:
10.55
Unit Pack:
1
Pallet Quantity:
100
UPC Code:
737238420583
Brand:
Meritor Genuine
Marketing Group:
176N Series
Spline Diameter:
2.390 in.
Series:
176N
Number of Splines:
46I
Hub Diameter:
3.25 in.
Spline Length:
2.32 in.
Center To End:
5.06 in.
Joint Angle:
34 degrees
Counter Bore Depth:
0.14 in.
Use U-Joint Kit:
M407X
Bearing Cap Diameter:
1.94 in.
Yoke Dim. Across Ears:
7.00 in.
VMRS Code:
024-001-003
| Part Number | Description |
|---|---|
| END YOKE | |
| END YOKE | |
| END YOKE | |
| AXLE ASSY-DRIVE | |
| END YOKE | |
| YOKE & DEFLECTOR ASSY | |
| YOKE & DEFLECTOR ASSY | |
| YOKE & DEFLECTOR ASSY |
| Reference Material: |
For measuring guideline instructions: Click here
|
| Xpress Facts: |
Driveline Product Information
|
| Competitor | Part Number |
|---|---|
| Dana | 6341031 |
| Other | 6341041X, 8235176NYS3814, ATI176NYS3814, SI6341041X, TDA176NYS3814 |
