Product Details
Specifications
BOM
Where Used
Reference Material
Part Interchange
Status:
Active
Weight:
10.21
Unit Pack:
1
Pallet Quantity:
100
UPC Code:
737238309291
Brand:
Meritor Genuine
Marketing Group:
Non-Slip Bearing Stubs
Number of Splines:
16
Spline Diameter:
2.350 in.
Insert Diameter:
3.74 in.
Bearing Shoulder Diameter:
2.362 in.
Spline Length:
2.63 in.
Use W/ Tubing OD And Wall:
4.09 in. x .180 in. (7 GA)
Thread Diameter:
1.25 in.
Related Nut:
1227Z936
Threads per Inch:
18
Effective Length:
5.31 in.
Style:
01
VMRS Code:
024-002-060
End Of Spline To Bearing Shoulder:
4.00 in.
Shoulder Diameter:
2.88 in.
Shoulder Length:
0.81 in.
Deflector Diameter:
3.32 in.
Related Washer:
WAR21-1
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|---|
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| YK, TUBE & STUB W/CTR PARTS | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| YK, TUBE & STUB W/CTR PARTS | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| YK, TUBE & STUB W/CTR PARTS | |
| ASSEMBLY-DOUBLE COUPLING | |
| YK, TUBE & STUB W:CTR PARTS | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| YK, TUBE & STUB W/CTR PARTS | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| ASSEMBLY-DOUBLE COUPLING | |
| YK, TUBE & STUB W:CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| SLIP ASSY-SPLINED,STANDARD | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS | |
| YK, TUBE & STUB W/CTR PARTS |
| Reference Material: |
For measuring guideline instructions: Click here
|
| Warranty Information: |
SP16165 - Cummins Drivetrain and Braking Systems Aftermarket Warranty
|
| Xpress Facts: |
Driveline Product Information
|
| Competitor | Part Number |
|---|---|
| Dana | 653311 |
| Neapco | N653311 |
| Other | 17N53311RI, 486530C1, 653311R, 823517N53311, ATI17N53311, HR17N53311, MER17N53311, S9120, SI653311, TDA17N53311 |
