Status:
Active
Weight:
8.50
Unit Pack:
1
Pallet Quantity:
180
UPC Code:
737238050872
Brand:
Meritor Genuine
Marketing Group:
Camshafts
Effective Length:
12.10 in.
Left or Right:
LH
Brake Diameter:
16.50 in.
Camshaft Spline Count:
10
Head Type:
11
Camshaft Spline Dia.:
1.50 in.
Bushing Journal Dia.:
1.50 in.
Bushing Journal Length:
1.77 in.
Brake Hardware Kit:
R509000 - P Brakes, KIT8000HD - Q Brakes
Camshaft Repair Kit:
KIT9078 - P Brakes; KIT8042 - Q Brakes
Paired Camshaft:
2210E5725
Axle:
Drive or Steer
OEM:
Meritor
Brake Type:
Q
VMRS Code:
013-017-004
| Part Number | Description |
|---|
| Catalog: |
PB8857 - Meritor Drum Brake and Wheel End Catalog
|
| Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
| Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
| Sales Publication: |
SP1980 - The Complete Brake Job
|
| Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
| Xpress Facts: |
Air Brake Product Information
|
| Competitor | Part Number |
|---|---|
| Automann | 12210120201 |
| BWP | M2610L |
| Eaton Top Spec | 72398 |
| Hercules | H10250L |
| Transit Parts | TP158 |
| Wagner | F31945 |
| Other | 04169, 18853, 2210F5726RI, 2368979, 4169, 430395C1, 4451222, 82352210F5726, ATI2210F5726, CAM264L, CS2715AL, CS41040, EUE2715A, L1685, R16WKL10124, TDA2210F5726 |
