Exclusive - Distributor Channel
Qty
Locate Dealer / Distributor
Product Details
Specifications
Where Used
Reference Material
Part Interchange
Alternate
Status:
Active
Weight:
7.83
Unit Pack:
1
Pallet Quantity:
240
UPC Code:
729374914811
Brand:
Euclid
Marketing Group:
Camshafts
Effective Length:
11.51 in.
Camshaft Spline Count:
10
Brake Diameter:
16.50 in.
Left or Right:
RH
Head Type:
11
Brake Type:
Q Plus
Camshaft Spline Dia.:
1.50 in.
Bushing Journal Dia.:
1.50 in.
Bushing Journal Length:
1.81 in.
Camshaft Repair Kit:
E3993B
Brake Hardware Kit:
E2769HD
Axle:
Drive
Paired Camshaft:
E1148C
OEM:
Meritor
VMRS Code:
013-017-004
Notes:
Improved heat treating through the Cam Bushing area for longer life.
| Part Number | Description |
|---|
| Catalog: |
100AB - Euclid Brake and Wheel End Catalog
|
| Inspection Guideline: |
TP1363 - Inspecting Foundation Cam Brakes
|
| Maintenance Manual: |
MM4 - Cam Brakes & ASAs Maintenance Manual
|
| Sales Publication: |
SP14137 - Brake Job Critical-Review Components
|
| Sales Publication: |
SP1980 - The Complete Brake Job
|
| Xpress Facts: |
Air Brake Product Information
|
| Competitor | Part Number |
|---|---|
| Automann | 12210111602, 12210111604 |
| BWP | M743R |
| D and E | D&E1147A |
| Eagle/Norcross | A8084 |
| Eaton | 180248, 72393 |
| Fleetpride | OTR1147C |
| HDA | B1058RB |
| Haldex | 41017, 65231, CS41017 |
| Hercules | H10017R, HQ10017R |
| Mack | 2210C5359S |
| Napa | 65321 |
| Navistar | 109520R1, 109520R1, 207184R1, 207185R1 |
| New Life/Fleetcraft | NL1301 |
| Nuturn - CAN | L507 |
| Power Equipment -PDC | 1147BP |
| Provincial Whse -CAN | M743R |
| Sirco Brake | C147CR |
| Spicer | 18810 |
| Trailmobile | 381147B, 70017244 |
| Tramec | 54040R |
| UBS | 28507 |
| Volvo | 843369 |
| Wabash Trailer | 41421147 |
