Status:
Active
Weight:
8.00
Unit Pack:
1
Pallet Quantity:
144
UPC Code:
884879634203
Brand:
Euclid Genuine
Marketing Group:
Gunite
Clevis Type:
Collar Lock Straight
Arm Length:
6.0 in.
Production Part Number:
AS1133
AllMakes or OE:
OE
Model:
Gunite
Slack Spline Diameter:
1.50 in.
Service Part Number:
AS1133
Slack Spline Count:
10
Aftermarket Extended Warranty - General:
1 Year - Standard Meritor Aftermarket Warranty
Sensing Type:
Clearance
Application:
Drive
Type:
Unhanded
OEM:
Gunite
Brake Size:
16.50 in.
Bushing Inside Diameter:
0.50 in.
Chamber Sizes:
Multiple
Notes:
Use clevis with 1.02 in. pin center.
VMRS Code:
013-017-005
Clevis Thread Diameter:
0.625 in.
Clevis Threads per inch:
18
Maximum Torque Rating:
Less than 15 foot pounds
Related Unclevised Number:
E-15002
Related Clevis Kit:
E-15069
| Part Number | Description |
|---|
| Catalog: |
100AB - Euclid Brake and Wheel End Catalog
|
| Xpress Facts: |
Air Brake Product Information
|
| Competitor | Part Number |
|---|---|
| Automann | 1381030 |
| Dana | 974295, M16WR1331 |
| Dayton Parts Batco | 05760 |
| Dexter | 5501105 |
| Freightliner | 764013506, GUNAS1033, GUNAS1133, GUNSA09903 |
| Fruehauf | ACF004205810 |
| Gunite | AS1033, AS1133 |
| Hendrickson | A15156 |
| Mack | 3398AS1033, 3398AS1133 |
| Navistar | ZBRAS1033, ZBRAS1133 |
| Sirco Brake | SA1133 |
| Volvo | 1090339, 3947846, 764010103, 8060850, 8084128 |
| Western Star | 764013499, 764013506 |
