Product Details
Specifications
BOM
Where Used
Reference Material
Part Interchange
Alternate
Status:
Active
Weight:
60.10
Unit Pack:
1
Pallet Quantity:
12
UPC Code:
193174201998
Brand:
Meritor
Marketing Group:
Flat
Rotor Depth:
1 3/4 in.
Rotor Depth (mm):
45 mm
Outside Diameter (mm):
430 mm
Pilot Diameter:
10 3/16 in.
Mounting Holes:
Splined
Outside Diameter:
16 15/16 in.
Bolt Hole Size:
Spline
Discard Thickness:
1 7/16 in. or 37 mm
Bolt Circle Diameter:
9 13/16 in.
OEM:
Bendix/Knorr
Type:
Flat
New Disc Thickness:
1 3/4 in. or 45 mm
Bolt Circle Diameter (mm):
250 mm
OEM Part:
802569
Pilot Diameter (mm):
258 mm
VMRS Code:
013-017-001
Bill of Materials:
Part No
Quantity
Description
| Part Number | Description |
|---|
| Catalog: |
PB1461 - Meritor Air Disc Brake Catalog
|
| Warranty Information: |
SP16165 - Cummins Drivetrain and Braking Systems Aftermarket Warranty
|
| Xpress Facts: |
Air Disc Brake Product Information
|
| Competitor | Part Number |
|---|---|
| A-Line | ATR432045000 |
| Airtex | 1531802569 |
| Automann | 1531802569 |
| Bendix | 802569 |
| Bens Truck Parts | 802569 |
| Conmet | 10023879 |
| Dayton Parts Batco | 125804 |
| Durabrake | 76692 |
| Fleetpride | OTR86793 |
| Hendrickson | S2915217 |
| Meritor | M44DH802569 |
| Webb | 56094PK |
| Other | 21538404, 8235M44DH802569, TDAM44DH802569 |
